UKI Template Guide

Introduction

A template is a read-only project file (.tpl) containing various settings specific to a studio or project. It includes attributes, project preferences, default settings, properties and classifications, and the content and structure of the Navigator and associated set-up.

Default templates are provided with Archicad, which include customisations based on local standards. These can be customised further to fine-tune based on your own projects and deliverables, to suit your own requirements. A good quality and well structured template is essential in working to best practises. It allows immediate project start up, increased productivity, project consistency, and ease of use by the design team.

When creating a new project, selecting the template to use is always the first step, incorporating the above settings into the new project file. Although there will likely be project-specific demands and requirements, a good quality template will act as a consistent starting point

Templates are updated periodically to account for any changes to workflow, project requirements, or new tools and features introduced in new versions of Archicad.

Online Templates

In the latest version of Archicad, the localised templates for the UK and Ireland (UKI) are hosted online, and are not part of the installation package. The available templates will automatically be downloaded on launching the software with an internet connection.

Any changes to the templates, including updated standards and classifications, can be made available much more quickly, without having to wait for new Archicad versions or updates to be released. Archicad will check for and download any updates to the online templates automatically when connected to the internet.

Where you are using the default templates, and have projects containing multiple files, it’s recommended to save a project-specific copy of the template for use across each project file. This will help ensure consistency in case the online templates are updated during the delivery of the project.

See below for information on current online templates available for the UK and Ireland, and associated template guides for more detailed information.

UKI Template

To assist our customers in the UK and Ireland, the UKI template has been specifically developed to offer an out-of-the-box solution to help adhere to recognised local standards, protocols, and workflows. Although these can be adapted to your studio’s specific requirements, the template aims to produce a standard set of drawings for UK plan of works without substantial customisation. This template is named simply with the version number i.e. “Archicad 28 Template“.

The UKI Template Guide gives detailed information on the template’s content, how to use it, and suggestions on how you might adapt it for your own specific project requirements.

AC30 UKI Template Guide (PDF) AC29 UKI Template Guide (PDF) AC28 UKI Template Guide (PDF)

UKI COBie Template

The UKI COBie template is based on the above UKI Template, but with further emphasis on IFC and COBie deliverables. Additionally including Uniclass classifications and a further IFC translator for COBie data, this should assist all users seeking to deliver COBie to their clients and make data exchange more robust and more reliable.

Uniclass classifications are updated on a quarterly basis, so the UKI COBie template will be updated throughout the year to reflect these changes.

COBie Template Guide (PDF) COBie Documentation

Sample Projects

This example project helps to demonstrate the utilisation of the UKI Template with practical examples. The project adheres to the template’s structure and content, with only minor customisation for project specific demands.

Farnsworth House

Farnsworth House is a steel and glass house constructed as a weekend retreat in Illinois, and is currently operated as a house museum. The Archicad project is highly developed and includes detailed construction drawings.

Download Archicad
Project (AC30) Download Archicad
Project (AC29) Download Archicad
Project (AC28) Download
BIMx

Note that this project may not include all of the most recent changes to the UKI Template, and is intended as a reference only.

Template Migration

With the annual Archicad updates, it is recommended that project templates are reviewed and upgraded in line with any changes in Archicad functionality. The UKI templates will be updated periodically to reflect any updates or changes to local standards. For information on updating your studio’s template in line with new versions of Archicad, take a look at our Archicad Template Upgrade workflow guides.

Workflow Guides

Learning

Graphisoft’s BIM Manager Program is a fun and interactive online program packed with presentations, advice and virtual activities. It includes modules on BIM office management, Archicad template creation, and projection coordination, and is a great opportunity to get up-to-date with BIM standards and best practices.

During the Archicad Template Creation module you will learn how to develop and manage different areas of your Archicad template, such as its structure, data, naming conventions, and QA mechanisms.
