Structural Analytical Model Data

Archicad can generate a Structural Analytical Model based on the architectural model and Generation Rules. This structural model can be exported in SAF format – see https://saf.guide – which contains all the relevant data from the Structural Analytical Model.
To ensure SAF data exchange between Archicad and Analysis softwares, Archicad’s SAF Translator must be properly configured.

The following files help you set up the SAF Translator‘s Material and Profile Mapping in a more automatic way:

The SAF Material and Cross Section Catalog files contain Materials and Manufactured Cross Sections with the proper terminology straight from the Analysis application.
Use these files for setting up the Material and Profile Mapping settings to ensure proper data exchange.

Notes:

  • The Cross Section catalog contains Manufactured Cross Sections only.
  • Catalog files are in SAF (xlsx) format.
  • We recommend using these SAF catalog files primarily for the SAF Export workflow.

How to use

1

Download SAF catalog file

2

Open File> Interoperability> SAF> SAF Translators …
Go to Export Translator > Material or Profile Mapping > Click on SAF Materials or SAF Cross Sections.

3

In the SAF Materials/Cross Sections dialog: click Import. Browse for the downloaded SAF catalog file.
The Catalog is imported into the SAF Export Translator.

See Archicad User Guide for the detailed steps.

Name Software Standard Filetype and version Last modification
Dlubal RFEM 6 Material Catalog INT Scia Engineer Eurocode SAF v1.0.5 25.10.21
Dlubal RFEM 6 Material Catalog US Scia Engineer AISC, ACI, AWS, ADM SAF v1.0.5 25.10.21
SCIA Engineer 20 Material Catalog INT Scia Engineer Eurocode SAF v1.0.5 04.02.21
SCIA Engineer 20 Material Catalog US Scia Engineer AISC, ACI, AWS, ADM SAF v1.0.5 07.12.20
SCIA Engineer 20 Profile Catalog INT Scia Engineer Eurocode SAF v1.0.5 07.12.20
SCIA Engineer 20 Profile Catalog US Scia Engineer AISC SAF v1.0.5 07.12.20
RISA-3D 19 Material Catalog US RISA-3D AISC, ACI, AWC, ADM SAF v1.0.5 22.12.20
RISA-3D 19 Profile Catalog US RISA-3D AISC SAF v1.0.5 22.12.20
AxisVM X5 Material Catalog EU AxisVM Eurocode SAF v1.0.5 07.12.20
AxisVM X5 Material Catalog US AxisVM ASTM, ACI SAF v1.0.5 07.12.20
AxisVM X5 Profile Catalog EU AxisVM Eurocode SAF v1.0.5 07.12.20
AxisVM X5 Profile Catalog US AxisVM AISC SAF v1.0.5 07.12.20
FEM-Design 19 Material Catalog EU FEM-Design Eurocode SAF v1.0.5 07.12.20
FEM-Design 19 Profile Catalog EU FEM-Design Eurocode SAF v1.0.5 07.12.20
